GROUP # / MONITORING / LOAD CURR’ ALARM / G-Pickup
Range
0(OFF), 10 ~ 1600A
Default
250
Step
1A
Set the detect current of load current alarm about ground current.
GROUP # / MONITORING / LOAD CURR’ ALARM / G-Time Delay
Range
0.00 ~ 600.00 sec
Default
0.00
Step
0.01sec
Set the detect time of load current alarm about the ground current.
GROUP # / MONITORING / LOAD CURR’ ALARM / Q-Pickup
Range
0(OFF), 10 ~ 1600A
Default
OFF
Step
1A
Set the detect current of load current alarm about negative sequence
current.
GROUP # / MONITORING / LOAD CURR’ ALARM / Q-Time Delay
Range
0.00 ~ 600.00 sec
Default
0.00
Step
0.01sec
Set the detect time of load current alarm about the negative sequence
current.
[LOAD CURR
’
ALARM]
Function: DISABLE
P-Pickup: 500
P-Time Delay: 0.00
>G-Pickup: 250
G-Time Delay: 0.00
[0(OFF),10~1600:1A]
[LOAD CURR
’
ALARM]
Function: DISABLE
P-Pickup: 500
P-Time Delay: 0.00
G-Pickup: 250
>G-Time Delay: 0.00
[0.00~600.0:0.01s]
[LOAD CURR
’
ALARM]
P-Time Delay: 0.00
G-Pickup: 250
G-Time Delay: 0.00
>Q-Pickup: OFF
Q-Time Delay: 0.00
[0(OFF),10~1600:1A]
[LOAD CURR
’
ALARM]
P-Time Delay: 0.00
G-Pickup: 250
G-Time Delay: 0.00
Q-Pickup: OFF
>Q-Time Delay: 0.00
[0.00~600.0:0.01s]
