Multi-Function Control ETMFC610 http://www.entecene.co.kr
22
EN
HANCED
TEC
HNOLOGY
Power Factor 1,2
Function ..................................................................... DISABLE/ENABLE
Pickup Level for Lag ................................................. OFF, 0.05 to 0.99 in steps of 0.01
Pickup Level for Lead ............................................... OFF, 0.05 to 0.99 in steps of 0.01
Time Delay ................................................................ 1.00 to 600.00sec in steps 0.01sec
Function Block Time After Close .............................. 0.05 to 600.00sec in steps 0.01sec
Level Accuracy .......................................................... ± 5%
Timing Accuracy ....................................................... ± 5% of setting time or ± 20msec
Live Line
Pickup Level .............................................................. 0.10 to 1.40xVT in steps of 0.01xVT
Time Delay ................................................................ 0.00 to 600.00sec in steps of 0.1sec
Dropout Level ........................................................... 95 to 98% of Pickup
Timing Accuracy ....................................................... ± 5% of setting time or ± 20msec
Operation Counter
Function ..................................................................... DISABLE/ENABLE
Alarm Count .............................................................. 1 to 20000 in steps of 1
Reset Count ............................................................... 0 to 10000 in steps of 1
Contact Wear
Function ..................................................................... DISABLE/ENABLE
Alarm Pickup Level................................................... 0.0 to 50.0% in steps of 0.1%
Time Delay ................................................................ 0.00 to 1.00s in steps 0.01s
Interruption Current at Point 1(Max. Operation) ...... 1.00 to 600.00kA in steps of 0.01kA
Number of Operation at Point 1(Max. Operation) .... 1 to 60000 in steps of 1
Interruption Current at Point 2(Min. Operation) ....... 1.00 to 600.00kA in steps of 0.01kA
Number of Operation at Point 2(Min. Operation) ..... 1 to 60000 in steps of 1
Set Phase A Wear ....................................................... 0.00 to 100.00 % in steps of 0.01%
Set Phase B Wear ....................................................... 0.00 to 100.00 % in steps of 0.01%
Set Phase C Wear ....................................................... 0.00 to 100.00 % in steps of 0.01%
