TARGET
Records the fault detect phase and event trigger source.
- A: A Phase Fault
- B: B Phase Fault
- C: C Phase Fault
- G: Ground Fault
- S: Sensitive Earth Fault
- Q : Negative Sequence Fault
SEQ
Fault sequence number (Applied when Fault Indication Type)
LOC
It registers Fault Location Information (location and reactance).
*. NOTE) 1. Indicated when “Fault Locater” function is ENABLE.
2. For more details about settings of “Fault Locater” function, refer to
“8.5.9. Fault Locator”.
FAULT
CURRENT
Max. Current value is indicated when fault is occurred.
It registers current of the each phase, ground, sensitive earth and negative
sequence.
Trigger Source
Please refer to “TARGET” and “TYPE” of the above mentioned Fault Event Information.
Trigger Time
Monitors changes of Trigger source status in every 1/4 cycle.
Trigger Capacity
Stores last 1,500 events.
*. NOTE ) The maximum number of events to be stored can be increased according to user
requests.
