Trigger Time
Monitors status of Trigger source in every 5msec.
Trigger type
Stores type of Trigger source : Pickup(assert) or Dropout(deassert)
Storage Capacity
Stores last 2,000 events.
*. NOTE ) The maximum number of events to be stored can be increased according to user
requests.
When Diagnostics Fail is occurred the treatment method is same as following.
Table 9-1. Treatment Method when Diagnostics Fail is occurred
No. Item Period Method
1 DSP Within 200msec Change to fault detect block
2 ADC 1/4 cycle Change to fault detect block
3 RTC 1 hour, at booting Change the date to January 1
st
, 2017
4 Memory 1 hour, at booting Restart
5 Flash-Rom
A
t
Flash
-
Rom
reading and
writing, at booting
Restart
6 Circuit voltage 1/4 cycle Change to fault detect block
7 Global setting At setting change, at booting
Change the
Global
setting value to
Default
value
8 Group # setting At setting change, at booting
Change the
Group #
setting value to
Default
value
9 Event At event save and reading Event initialization
10 Count At counter writing and reading Counter initialization
11 DO signal 50msec Output power block
12 Close/Open At closing and opening Necessary to check in local
