GLOBAL SETTING / GENERAL / SYSTEM / VOLTAGE SENSING / 1V Rated(P-P)
Range
3.00~38.00kV
Default
22.86
Step
0.01kV
Enter the primary rated voltage (kV) of potential transformer for
Source Voltage Connector (1V).
This setting refers to primary rated voltage in the line voltage (phase-
to-phase).
GLOBAL SETTING / GENERAL / SYSTEM / VOLTAGE SENSING / 1V Ratio
Range
10.0~6500.0
Default
3300.0
Step
0.01
Enter the rated rate of potential transformer for Source Voltage
Connector (1V).
GLOBAL SETTING / GENERAL / SYSTEM / VOLTAGE SENSING / 2V Connect Type
Range
NONE, WYE, DELTA
Default
WYE
Step
~
Select the voltage type of system that input to Load Voltage Connector
(2V).
 NONE : VT none installed. Select NON
 WYE : If Voltage Connect Type is Y-Type, Select WYE.
 DELTA : If Voltage Connect Type is Δ-Type, Select DELTA.
GLOBAL SETTING / GENERAL / SYSTEM / VOLTAGE SENSING / 2V Rated(P-P)
Range
3.00~38.00kV
Default
22.86
Step
0.01kV
Enter the primary rated voltage (kV) of potential transformer for Load
Voltage Connector (2V).
This setting refers to primary rated voltage in the line voltage (phase-
to-phase).
[VOLTAGE SENSING]
>1V CON-Type: WYE
>1V Rated(P-P):22.86
1V Ratio: 3300.0
2V CON-Type: WYE
2V Rated(P-P):22.86
[3.00~38.00:0.01kV]
[VOLTAGE
SENSING]
>1V CON-Type: WYE
>1V Rated(P-P):22.86
>1V Ratio: 3300.0
2V CON-Type: WYE
2V Rated(P-P):22.86
[10.0~6500.0:0.01]
[VOLTAGE SENSING]
>1V CON-Type: WYE
>1V Rated(P-P):22.86
>1V Ratio: 3300.0
>2V CON-Type: WYE
>2V Rated(P-P):22.86
[NONE/WYE/DELTA]
[VOLTAGE SENSING]
>1V CON-Type: WYE
>1V Rated(P-P):22.86
>1V Ratio: 3300.0
>2V CON-Type: WYE
>2V Rated(P-P):22.86
[10.0~6500.0:0.01]
