6.6.2. Setting
PRIMARY SETTING / SYSTEM SETUP / OPTO INPUT SET / I1 Func
Range
NONE, TRIP, … , OUT8 RESET
Default
NONE
Step
~
Enter the function of External input terminal Opto input can have
following functions.
NONE TRIP CLOSE
PROTECTION
Enable/Disable
GROUND
Enable/Disable
SEF
Enable/Disable
RECLOSE
Enable/Disable
CONTROL
Locked/Unlocked
ALTERNATE SETTINGS
Enable/Disable
PROGRAM1
Enable/Disable
PROGRAM2
Enable/Disable
HOT LINE TAG
Enable/Disable
FAULT INDICATION
RESET
BATTERY LOAD TEST
OUTPUT RELAY
1∼8 RESET.
For more details, refer to “Appendix A. OPTO INPUT FUNCTION”.
PRIMARY SETTING / SYSTEM SETUP / OPTO INPUT SET / I1 Debounce
Range
0.01 ~ 9.99 sec
Default
0.02
Step
0.01 sec
Enter debounce time to prevent chattering in Input
Input 2 ~ Input 8, the same as Input 1 above
[OPTO INPUT SET]
I1 Func: NONE
>I1 Debounce: 0.02
I2 Func: NONE
[OPTO INPUT SET]
>I1 Func: NONE
I1 Debounce: 0.02
I2 Func: NONE
