8. MONITORING
EVRC2A has Monitoring function for following items and also has functions for user to output
Alarm signal or Trip signal.
y DEMAND
y SYNCHRO CHECK
y TRIP COUNTER
y RECLOSER WEAR
y BATTERY TEST
y FAULT LOCATOR
y GAS LOW LOCK – Option
y EXT’ TRIP & LOCK – Option
y LIVE LOAD BLOCK – Option
8.1. Demand
8.1.1. Description
EVRC2A is programmed to monitor following items to be operated as user sets.
y Phase Current demand value
y Ground current demand value
y Negative sequence current demand value
8.1.2. Related Setting Menu
1) Function Setting
Select for system to operate when Demand elements were picked up.
PRIMARY SETTING / MONITORING / DEMAND / Function
Range
OFF, TRIP, TR&AR
Default
OFF
Step
~
OFF : OFF Monitoring
TRIP : Generates Trip signal
TR&AR : Generate Trip and Alarm signal
[DEMAND]
>Function: OFF
Relays(0-8): OFF
Type: THM
