3. USER INTERFACE PANEL
This section describes the User Interface Panel (front-panel)
The User interface Panel control is used for;
y Directly control the recloser
y Verify control status
y View system status
y View metering value
y View information stored in the EVRC2A unit
y View and change the EVRC2A settings
Figure 3-1. User Interface Panel
