10.1. Metering Elements
10.1.1. Current
The following values are contained in the current metering.
IA : Displays the measured phase A RMS current and phasor (A, Lag)
IB : Displays the measured phase B RMS current and phasor (A, Lag)
IC : Displays the measured phase C RMS current and phasor (A, Lag)
IG : Displays the measured ground RMS current and phasor (A, Lag)
ISG : Displays the measured sensitive earth RMS current and phasor (A, Lag)
I2 : Displays the calculated negative sequence RMS current (A)
You can confirm in “MAIN MENU / METERING / CURRENT”
MAIN MENU / METERING / CURRENT
[LINE CURRENT(A)]
A: 0 B: 0
C: 0 G: 0
SG: 0 I2: 0
[PHASE A CURRENT]
0 A 0.0 Lag
[PHASE B CURRENT]
0 A 0.0 Lag
[PHASE C CURRENT]
0 A 0.0 Lag
[GROUND CURRENT]
0 A 0.0 Lag
[SENSTV CURRENT]
0 A 0.0 Lag
[POS SEQ CURRENT]
0A 0.0 Lag
[NEQ SEQ CURRENT]
0A 0.0 Lag
[ZERO SEQ CURRENT]
0A 0.0 Lag
Display measured values of current and current phase per phase. Use [▲] [▼] button to check
metering information of current.
