12.3. Load Profile
Record the Demand value when reaches in setting time (5, 10, 15, 20, 30, 60minute). Load
profile has 5120 Banks that can store values of 213 days if setting time is 60minute.
LOAD PROFILE
①
②
③
④
Confirm in
”MAIN MENU / EVENT RECORDER / LOAD PROFILE”
y To see previous value, press [▲] key.
y To see next value, press [▼] key.
y On screen ①, use [◀] or [▶] key to see ①, ②, ③, ④ screen in
term.
12.3.1. Trigger Source
y Demand Current(A, B, C, G)
y Demand Real Power(A, B, C, 3ф)
y Demand Reactive Power(A, B, C, 3ф)
y Demand Power Factor( 3ф)
y Demand Energy - Positive Watthour(3ф), Positive Varhour(3ф)
12.3.2. Trigger Time
y 5, 10, 15, 20, 30, 60 Minute
12.3.3. Storage Capacity
y Stores 5120 events
PF&ENERGY-3P [0001]
P-F(%) : 0.0
MWh: 0.0 MVh: 0.0
10/01/22 21:45:00
REAC POW(Mvar)[0001]
A : 0 B : 0
C : 0 3P: 0
10/01/22 21:45:00
REAL POW(MW) [0001]
A : 0 B : 0
C : 0 3P: 0
10/01/22 21:45:00
CURRENT (A) [0001]
A: 0 B: 0
C: 0 G: 0
10/01/22 21:45:00
