13.31. Analog Board
Figure 13-31. ANALOG BOARD
y JP1, JP2, JP3 are Jumper Connecter, defining User Available DC Power Output Rating.
y F1, F2 are use to protect IGBT for Close and Trip.
y F3 is for Relay Module protection.
y JP1, JP2, JP3 are Jumper Connectors and define User Available DC Power rating.
