2.7. Communications
Table 2-2. Communications
Front Panel Port1
RS232, 57600bps, No Parity, 8 Data Bits, 1 Stop bit
EVRC2A Interface software
Side panel Port2 - Option
RS232, 1200-19200bps, No Parity, 8 Data bits, 1 Stop bit
DNP 3.0, Modbus or IEC60870-5-101 Protocol
and EVRC2A Interface software
Side panel Port3 – Option
RS485 or RS232*, 1200-19200bps, No Parity, 8 Data bits, 1
Stop bit
DNP 3.0, Modbus or IEC60870-5-101 Protocol
and EVRC2A Interface software
Side panel Port4 – Option
RJ-45, 10BASE-T/100BASE-T
DNP 3.0, Modbus or IEC60870-5-104 Protocol,
and EVRC2A Interface software
NOTE :
The Port3 type of EVRC2A-N is a fixed RS485 port. However, the Port3 type of
EVRC2A-N6,NT can be selected as RS485 or RS232 by a user. In order to use
RS485 port for EVRC2A-N6,NT, the Pin4 and Pin5 of RS485 should be connected.
