8.3. Trip Counter
8.3.1. Trip Counter Explanation
EVRC2A records counter related with System operation. Especially Trip Counter is operated
depending on Monitoring function set by user.
y Trip : Records trip operation count
y Fault : Records Fault count
y System Restart : Records system restart count
MAIN MENU / MAINTENANCE / COUNTERS
User can confirm in “MAIN MENU/MAINTENANCE/COUNTERS”
8.3.2. Related Setting Menu
1) Function Setting
Select for system to operate when Trip Counter reaches Limit value set by user.
PRIMARY SETTING / MONITORING / TRIP COUNTER / Function
Range
OFF, ALARM
Default
OFF
Step
~
OFF : OFF Monitoring
ALARM : Generate Alarm signal
2) Alarm Output Relay Setting
Select Relay output for alarm.
PRIMARY SETTING / MONITORING / TRIP COUNTER / Relays(0-8)
Range
OFF, 0 ~ 8
Default
OFF
Step
1
Maximum 4 of Relay outputs can be selected to operate output signal.
0000(off) : No Output Relay is selected.
1234 : Operate output signal through 1, 2, 3, 4 Output Relay.
[TRIP COUNTER]
Function: OFF
>Relays(0-8): OFF
Limit: 10000
[TRIP COUNTER]
>Function: OFF
Relays(0-8): OFF
Limit: 10000
[ COUNTER ]
1.TRIP : 00000
2.FAULT : 00000
3.RESTART: 00011
