PRIMARY SETTING / MONITORING / SYNCHROCHECK / L.V.Min(xVT)
Range
0.00 ~ 1.25
Default
0.85
Step
0.01
Enter the live line minimum voltage for synchronism check.
Used to activate the synchronism check element for voltage over this
level.
PRIMARY SETTING / MONITORING / SYNCHROCHECK / M.V.D(V)
Range
0.00 ~ 1.25
Default
0.10
Step
0.01
Enter the maximum voltage difference of the synchronism voltages.
A voltage magnitude differential of the two input voltages below this
value is within the permissible limit for synchronism.
PRIMARY SETTING / MONITORING / SYNCHROCHECK / M.A.D(Deg)
Range
0 ~ 100 deg
Default
15
Step
1 deg
Enter the maximum angle difference of the synchronism voltages.
An angular differential between the synchronism voltage angles below
this value is within the permissible limit for synchronism.
PRIMARY SETTING / MONITORING / SYNCHROCHECK / M.F.D(Hz)
Range
0.00 ~ 5.00 Hz
Default
2.00
Step
0.01 Hz
Enter the maximum frequency difference of the synchronism voltages.
A frequency differential between the synchronism voltages below this
value is within the permissible limit for synchronism.
PRIMARY SETTING / MONITORING / SYNCHROCHECK / Sync Phase
Range
R(AB), S(CB), T(AC)
Default
R(AB)
Step
~
Select the synchronism check phase on load side.
[SYNCHROCHECK]
M.A.D(Deg): 15
M.F.D(Hz): 2.00
>Sync Phase: R(AB)
[SYNCHROCHECK]
M.V.D(V): 0.10
M.A.D(Deg): 15
>M.F.D(Hz): 2.00
[SYNCHROCHECK]
L.V.Min(xVT): 0.85
M.V.D(V): 0.10
>M.A.D(Deg): 15
[SYNCHROCHECK]
D.V.Max(xVT): 0.50
L.V.Min(xVT): 0.85
>M.V.D(V): 0.10
[SYNCHROCHECK]
Relays(0-8): OFF
D.V.Max(xVT): 0.50
>L.V.Min(xVT): 0.85
