13.4. Earth Wiring Diagram
Figure 13-4. Earth Wiring Diagram
y After installation of Control cubicle, connect the ground.
y Earth Terminal can connect with core of cable size up to 12㎜(0.470") diameter.
y Earth cable from Pole Neutral and from EVRC2A Earth Terminal must be connected to the
ground.
