5.4. Event Recorder
Event Recording elements are set such as Recording and Sampling timing and so on.
Move to “PRIMARY, ALTERNATE or EDITBANK SETTING / RELAY SETUP / EVENT
RECORDER” to select setting for the event recording elements.
RELAY SETUP / EVENT RECORDER / Fault Cycle
Range
ON, OFF
Default
ON
Step
~
Select On or Off for Fault Cycle recording.
Recorded Fault Cycle can be viewed in menu, “EVENT
RECORDER”.
RELAY SETUP / EVENT RECORDER / Len’ of Pre F
Range
0 ~ 14 cycle
Default
4
Step
1 cycle
Enter the length of prefault in fault cycle.
RELAY SETUP / EVENT RECORDER / Load Profile
Range
ON, OFF
Default
ON
Step
~
Select On or Off for Load Profile recording.
Recorded Load Profile can be viewed in menu, “EVENT
RECORDER”.
RELAY SETUP / EVENT RECORDER / L.P save time(m)
Range
5,10, 15,20,30,60 min
Default
15
Step
~
Set Load Profile recording interval.
[EVENT RECORDER]
>Fault Cycle: ON
>Len’ of Pre F: 4
>L.P save time(m):15
[EVENT RECORDER]
>Fault Cycle: ON
>Len’ of Pre F: 4
>Load Profile: ON
[EVENT RECORDER]
>Fault Cycle: ON
>Len’ of Pre F: 4
>Load Profile: ON
[EVENT RECORDER]
>Fault Cycle: ON
>Len’ of Pre F: 4
>Load Profile: ON
