12.2. System Event Recorder
Record changes of system status up to 2048 lists when trigger source asserted and deasserted.
MAIN MENU / EVENT RECORDER / SYSTEM STATUS
Confirm in
”MAIN MENU / EVENT RECORDER / SYSTEM STATUS”
12.2.1. Trigger Source
y Protection Element
y 52A Contact
y Sequence status
y Front panel control
y AC supply
y External control
y Fail operation
y External input status
y System alarm etc.
y V1(Source), V2(Load)
y Power Quality detect
NOTE :
For more details about Trigger Source, refer to
“Appendix C. EVENT TEXT &
DESCRIPTION”
.
12.2.2. Trigger Time
Monitors changes of Trigger source status in every 1/4 cycle.
12.2.3. Trigger type
Stores type of Trigger source : Pickup(assert) or Dropout(deassert)
12.2.4. Storage Capacity
Stores last 2048 events.
12.2.5. Related Setting Menu
System automatically maintains system event recorder. User can clear only stored events.
1) Stored Value Clear
Select “2.SYSTEM STATUS” in “PRIMARY SETTING / RELAY SETUP / CLEAR
SAVED DATA” to clear.
[NO-0001] SLEEP MODE
STATUS : LO/DEASSERT
DATE : 10/01/22
TIME : 19:51:58:387
