8.4. Recloser Wear
8.4.1. Recloser Wear Explanation
Maintenance of contact life of Recloser. Manages the contact life calculated from fault current
size when faults interrupted. The initial value is 100%
MAIN MENU / MAINTENANCE / WEAR MONITOR
User can confirm in
“MAIN MENU / MAINTENANCE / WEAR MONITOR”
Phase A Wear : Shows phase A contact life.
Phase B Wear : Shows phase B contact life.
Phase C Wear : Shows phase C contact life.
8.4.2. Related setting menu
1) Function Setting
PRIMARY SETTING / MONITORING / RECLOSER WARE / Function
Range
OFF, ALARM
Default
ALARM
Step
~
Select for system to operate when Recloser wear elements were picked
up.
2) Pickup Setting
PRIMARY SETTING / MONITORING / RECLOSER WARE / Pickup(%)
Range
0.0 ~ 50.0 %
Default
20.0
Step
0.1 %
Enter Pickup value of contact life.
3) Rated Voltage Setting
PRIMARY SETTING / MONITORING / RECLOSER WARE / Rated Volt(kV)
Range
15, 27, 38 ㎸
Default Note Step
~
Select rated voltage.
NOTE :
The rated voltage determines the Recloser type.
[RECLOSER WEAR]
Function: ALARM
Pickup(%): 20.0
>Rated Volt(kV): 15
[RECLOSER WEAR]
Function: ALARM
>Pickup(%): 20.0
Rated Volt(kV): 15
[RECLOSER WEAR]
>Function: ALARM
Pickup(%): 20.0
Rated Volt(kV): 15
[WEAR MONITOR (%)]
1.CONTACT A : 98.70
2.CONTACT B : 98.70
3.CONTACT C : 98.70
