13.37. Recloser 52 contact and 69 contact
Table 13-13. 52 contact and 69 contact
Description Pin Function
69 is b Contact when unlocked.
T 69b(Monitored locked)
U Common(52 and 69)
V 52b(Monitored Trip)
W 52a(Monitored Close)
a 52 common(Auxiliary)
b 52b(Auxiliary)
c 52a(Auxiliary)
13.38. Recloser Trip and Close Coil
Table 13-14. Trip and Close Coil
Description Pin Function
1) Pin d, e and f are combined as one line.
2) Pin g, h and j are combined and placed as one
line
3) Pin m, p and r are combined and placed as one
line.
4) Close Coil Resistance : < 5Ω
5) Trip Coil Resistance : < 2Ω
d Close and Trip Coil Common
e Close and Trip Coil Common
f Close and Trip Coil Common
g Close Coil
h Close Coil
j Close Coil
m Trip Coil
p Trip Coil
r Trip Coil
