3.3. Using the LCD Menu
Starting mode Screen appears after powering on Control and initializing System.
INITING LOGO
Starting mode Message Display.
Control : Control Status displays
Breaker : Breaker Status displays
Battery : Battery Voltage displays
Gas : Gas Status displays
On Starting mode screen, to see Main Menu, press [FUN] key. Use [▲] [▼] key to select sub-
menu. When cursor is in top menu, if you press [▲] key, you go to the bottom menu due to
Rotation Menu Algorithm.
MAIN MENU
Main Menu consists of 8 sub-menus.
You can choose any sub-menu by using [▲] [▼] key.
Press [ENT] key to select the sub-menu.
As above explanation, you can move and select sub-menu.
3.3.1. View Example
To see External input port status. Move to “MAIN MENU / STATUS / OPTO INPUTS”.
The following screen is displayed.
STATUS / OPTO INPUTS
OPEN : Shows External Input is de-asserted,
CLOSE : Shows External Input is asserted.
Only 4 lines are displayed on LCD Screen, use [▲] [▼] key to see next
lines.
EVRC2A-SYSTEM STATUS
CONTROL : NORMAL
BREAKER : CLOSE
BAT:27.49 GAS: NOGAS
[MAIN MENU]
>1.SELECT SETBANK
>2.PRIMARY SETTING
>3.ALTERNATE SETTING
>4.EDITBANK SETTING
>5.STATUS
>6.METERING
>7.MAINTENANCE
>8.EVENT RECORDER
[OPTO INPUTS]
>Input 1: OPEN
>Input 2: CLOSE
>Input 3: OPEN
>Input 4: OPEN
>Input 5: OPEN
>Input 6: OPEN
>Input 7: OPEN
>Input 8: CLOSE
>Door st: CLOSE
