Entec EVRC2A-N6-NT - 11.3. Output Relay Test

RECLOSER CONTROL EVRC2A-N6,NT http://www.entecene.co.kr
238
ENHANCED TECHNOLOGY
11.3. Output Relay Test
EVRC2A is capable to perform the output test of the relay output ports(1~8). For the output test,
go to “MAINTENANCE / OUTPUT RELAY TEST” menu.
MAINTENANCE / OUTPUT RELAY TEST
①
②
③
④
Select output signal at ① for testing.
Press [ENT] button and then ② is shown.
Press [FUN] button at ② and then ③ is shown. The output signal has
been “asserted” for 2 sec. If the test is completed, the message, “END
TESTING”, is shown and then back to the previous menu.
If the [ESC] button is press at ②, ④ is shown and the output test is
canceled.
[OUTPUT RELAY TEST]
SELECT RELAY :RLY 1
Press <FUN> : Start
TEST Canceled
[OUTPUT RELAY TEST]
SELECT RELAY :RLY 1
Press <FUN> : Start
TESTING
[OUTPUT RELAY TEST]
SELECT RELAY :RLY 1
Press <FUN> : Start
Press <ESC> : Cancel
[OUTPUT RELAY TEST]
SELECT RELAY :RLY 1
