13.19. AC Power Cable
TYPE : MS22-2S(Female)
Cable Length : 2C-3.5㎟ 6meter(236")
A PIN Wire Color : White(Phase)
B PIN Wire Color : Black(Neutral)
C PIN : not connected
13.20. Fuses
Table 13-4. Fuses
Positions
Rating /
External AC - Power Input
Dimensions Purpose
Terminal Block TF1
7A/220Vac
15A/110Vac
0.25×1.25"
(6.385×31.75)㎜
Input Line of Transformer in UPS
Module AC Power
Terminal Block TF2
3A/220Vac
6A/110Vac
0.25"×1.25"
(6.385×31.75)㎜
Input Line of Transformer in
Control EVRC2A AC Power.
Terminal Block TF3 10A
0.25"×1.25"
(6.385×31.75)㎜
AC Power outlet and Heater
User Available AC Power
Inside Relay Module F1
(Analog board)
1A
0.197"×0.787"
(5×20)㎜
Trip Control
Inside Relay Module F2
(Analog board)
1A
0.197"×0.787"
(5×20)㎜
Close Control
Inside Relay Module F3
(Analog board)
2A
0.197"×0.787"
(5×20)㎜
Relay Module Power
Inside Relay Module F4
(Analog board)
5A
0.197"×0.787"
(5×20)㎜
User-Available DC Power
