4) Interrupter capacity setting
PRIMARY SETTING / MONITORING / RECLOSER WARE / Interrupt(kA)
Range
5.0 ~ 50.0 kA
Default
16
Step
0.1 kA
Enter the capacity of rated Interrupter.
5) Maximum Rated Interruption Number Setting
PRIMARY SETTING / MONITORING / RECLOSER WARE / No. Max I
Range
1 ~ 999
Default
100
Step
1
Enter the capacity of rated Interrupter.
6) Clear value Setting
Use to synchronize EVRC2A contact wear with Recloser contact wear.
PRIMARY SETTING / MONITORING / RECLOSER WARE / A Wear Set
Range
0.00 ~ 100.00 %
Default
100.00
Step
0.01 %
Enter a value of Phase A ’s contact wear.
PRIMARY SETTING / MONITORING / RECLOSER WARE / B Wear Set
Range
0.00 ~ 100.00 %
Default
100.00
Step
0.01 %
Enter a value of Phase B ’s contact wear.
PRIMARY SETTING / MONITORING / RECLOSER WARE / C Wear Set
Range
0.00 ~ 100.00 %
Default
100.00
Step
0.01 %
Enter a value of Phase C ’s contact wear.
[RECLOSER WEAR]
>A Wear Set: 100.0
>B Wear Set: 100.0
>C Wear Set: 100.0
[RECLOSER WEAR]
>A Wear Set: 100.0
>B Wear Set: 100.0
>C Wear Set: 100.0
[RECLOSER WEAR]
>A Wear Set: 100.0
>B Wear Set: 100.0
>C Wear Set: 100.0
[RECLOSER WEAR]
Rated Volt(kV): 15
Interrupt(kA): 12.5
>No. Max I: 100
[RECLOSER WEAR]
Pickup(%): 20.0
Rated Volt(kV): 15
>Interrupt(kA): 12.5
