10.1.2. Voltage(Souce Side, Load Side)
The following values are contained in the voltage metering.
A-N : Displays the measured A-N RMS voltage and phasor(㎸, Lag)
B-N : Displays the measured B-N RMS voltage and phasor(㎸, Lag)
C-N : Displays the measured C-N RMS voltage and phasor(㎸, Lag)
A-B : Displays the measured A-B RMS voltage and phasor(㎸, Lag)
B-C : Displays the measured B-C RMS voltage and phasor(㎸, Lag)
C-A : Displays the measured C-A RMS voltage and phasor(㎸, Lag)
AVERAGE PHASE : Displays the calculated average of the RMS phase voltage(㎸)
AVERAGE LINE : Displays the calculated average of the RMS line voltage(㎸)
POS SEQ : Displays the calculated positive sequence RMS voltage and phasor(㎸, Lag)
NEG SEQ : Displays the calculated negative sequence RMS voltage and phasor(㎸, Lag)
ZERO SEQ : Displays the calculated zero sequence RMS voltage and phasor (㎸, Lag)
You can confirm in “MAIN MENU / METERING / S-VOLTAGE or L-VOLTAGE”
MAIN MENU / METERING / S-VOLTAGE or L-VOLTAGE
[VOLTAGE (kV)]
AN: 0.00 AB: 0.00
BN: 0.00 BC: 0.00
CN: 0.00 CA: 0.00
[AVERAGE PHASE]
VOLTAGE --> 0.00
[AVERAGE LINE]
VOLTAGE --> 0.00
[PHASE A-N VOLTAGE]
0.00 kV 0.0 Lag
[PHASE B-N VOLTAGE]
0.00 kV 0.0 Lag
[PHASE C-N VOLTAGE]
0.00 kV 0.0 Lag
[LINE A-B VOLTAGE]
0.00 kV 0.0 Lag
[LINE B-C VOLTAGE]
0.00 kV 0.0 Lag
[LINE C-A VOLTAGE]
0.00 kV 0.0 Lag
[POS SEQ VOLTAGE]
0.00 kV 0.0 Lag
[NEG SEQ VOLTAGE]
0.00 kV 0.0 Lag
[ZERO SEQ VOLTAGE]
0.00 kV 0.0 Lag
Display measured values of voltage and voltage phase. Use [▲] [▼] button to check metering
information of voltage.
