RECLOSER CONTROL EVRC2A-N6,NT http://www.entecene.co.kr
94
ENHANCED TECHNOLOGY
6.7.2. Setting
PRIMARY SETTING / SYSTEM SETUP / OUTPUT RELAY SET / O1 Func
Range
NONE, TRIP, … , NEQ FLT
*
Default
NONE
Step
~
Enter the function of External output terminal.
Output Relay can have following function.
NONE TRIP CLOSE
FAIL TRIP FAIL CLOSE FAIL AC
FAIL BATTTERY 27 ELEMENT 59 ELEMENT
25 ELEMENT 81 ELEMENT 79 RESET
79CYCLE 79LOCKOUT SELFCHECK
PROTECTION Enable GROUND Enable SEF Enable
RECLOSE Enable CONTROL Locked REMOTE Enable
ALTERNATE SETTINGS
Enable
PROGRAM1 Enable PROGRAM2 Enable
HOT LINE TAG Enable LO/RE OPEN ALARM
CLOSE - 52A INPUT 1~ 8 GAS LOW*
OPEN - 52B* SYSTEM OK* CLOSE BLOCK*
MECHANISM LOCK* GAS LOW LOCK* EXT’ TRIP LOCK*
INST FAULT* DELAY FAULT*
HIGH CURRENT
LOCKOUT FAULT*
PHASE FAULT* GROUND FAULT* SEF FAULT*
NEQ FAULT*
For more detail, refer to “Appendix B. RELAY OUTPUT
FUNCTION”.
NOTE :
The function marked with ‘*’ is an option. That function
may not be supported by the option type.
PRIMARY SETTING / SYSTEM SETUP / OUTPUT RELAY SET / O1 Type
Range
PULSE, LATCH, S/R LATCH
Default
S/R LATCH
Step
~
S/R LATCH: Output signal is delivered only this function activates (ON).
PULSE: Output signal is delivered only during PULSE T. To activate
Output again, turn this function OFF and then, turn it ON again.
LATCH: Output signal is delivered once this function ON. To turn it
off, it needs Reset signal and it is set in “OPTO INPUT SET”
[OUTPUT RELAY SET]
O1 Func: NONE
>O1 Type: S/R LATCH
O1 Pulse T: 0.05
[OUTPUT RELAY SET]
>O1 Func: NONE
O1 Type: S/R LATCH
O1 Pulse T: 0.05
