SYSTEM SETUP / POWER QUALITY / SAG Duration (Option)
Range
1~60 cycle
Default
5
Step
1
Set a detect time for voltage sag(voltage low).
SYSTEM SETUP / POWER QUALITY / SWL Func (Option)
Range
Disable, Enable
Default
Disable
Step
~
It is to set event recording of swell enable or disable.
SYSTEM SETUP / POWER QUALITY / SWL Pickup (Option)
Range
1.05 ~ 1.25 × VT(secondary nominal voltage)
Default
1.20
Step
0.01
Set a detect level of voltage swell(high voltage) for Power Quality.
Detect level is set by multiplying a set value in here to source side rated
voltage.
SYSTEM SETUP / POWER QUALITY / SWL Duration (Option)
Range
1~60 cycle
Default
5
Step
1
Set a detect time for voltage swell(voltage high).
SYSTEM SETUP / POWER QUALITY / UBI Func (Option)
Range
Disable, Enable
Default
Disable
Step
~
It is to set event recording of current unbalance enable or disable.
NOTE :
This setting is supported from version 6.12 of EVRC2A-
N6,NT.
> [POWER QUALITY]
>UBI Func: Disable
>UBI Pickup: 30
>UBI Duration: 4.0
> [POWER QUALITY]
>SWL Func: Disable
>SWL Pickup: 1.20
>SWL Duration: 20
> [POWER QUALITY]
>SWL Func: Disable
>SWL Pickup: 1.20
>SWL Duration: 20
> [POWER QUALITY]
>SAG Pickup: 0.80
>SAG Duration: 5
>SWL Func: Disable
> [POWER QUALITY]
>SAG Func: Disable
>SAG Pickup: 0.80
>SAG Duration: 5
