RECLOSER CONTROL EVRC2A-N6,NT http://www.entecene.co.kr
123
ENHANCED
TECHNOLOGY
PRIMARY SETTING / PROTECTION / OPERATIONS / Lockout-NEQ
Range
1 ~ 5
Default
4
Step
1
Select the total number of the negative sequence trip operations.
This setting is used to change the total number of the negative sequence
trip operations.
PRIMARY SETTING / PROTECTION / OPERATIONS / Fast Curve-PHA
Range
0 ~ 5
Default
2
Step
1
Select the number of the phase fast curve operations.
This setting is used to change the number of the phase fast curve
operations.
The difference between setting [OPERATION] Lockout-PHA and
setting [OPERATION] Fast Curve-PHA is the number of remaining
phase delay curve operations.
PRIMARY SETTING / PROTECTION / OPERATIONS / Fast Curve-GND
Range
0 ~ 5
Default
2
Step
1
Select a number for the ground fast curve operations.
This setting is used to change the number of the ground fast curve
operations.
The difference between setting [OPERATION] Lockout-GND and
setting [OPERATION] Fast Curve-GND is the number of remaining
ground delay curve operations.
PRIMARY SETTING / PROTECTION / OPERATIONS / Fast Curve-NEQ
Range
0 ~ 5
Default
2
Step
1
Select a number for the negative sequence fast curve operations.
This setting is used to change the number of the negative sequence fast
curve operations.
The difference between setting [OPERATION] Lockout-NEQ and
setting [OPERATION] Fast Curve-NEQ is the number of remaining
negative sequence delay curve operations.
[OPERATIONS]
Fast Curve-PHA: 2
Fast Curve-GND: 2
>Fast Curve-NEQ: 2
[OPERATIONS]
Lockout-SEF: 4
Fast Curve-PHA: 2
>Fast Curve-GND: 2
[OPERATIONS]
Lockout-GND: 4
Lockout-SEF: 4
>Fast Curve-PHA: 2
[OPERATIONS]
Lockout-GND: 4
Lockout-SEF: 4
>Lockout-NEQ: 4
