PRIMARY SETTING / PROTECTION / H/C TRIP-GND / Time Delay
Range
0.00 ~ 10.00 sec
Default
0.00
Step
0.01 sec
The Time delay of phase high current trip setting programs a definite
time delay for the phase high current trip. If set to zero, phase high
current trip operates instantaneously.
PRIMARY SETTING / PROTECTION / H/C TRIP-GND / Active Trip
Range
OFF, 1 ~ 5
Default
OFF
Step
1
If Active Trip = OFF, the feature is not operate.
If Active Trip = 2, then phase high current trip is enabled for the
second trip operation and every following trip operation.
[ H/C TRIP-GND ]
Pickup(A): 4000
Time Delay: 0.00
>Active Trip: OFF
[ H/C TRIP-GND ]
Relays(0-8): OFF
Pickup(A): 4000
>Time Delay: 0.00
