RECLOSER CONTROL EVRC2A-N6,NT http://www.entecene.co.kr
149
ENHANCED TECHNOLOGY
PRIMARY SETTING / PROTECTION / H/C LOCKOUT-PHA / Pickup(A)
Range
10 ~ 20000 A
Default
8000
Step
1A
Set the pickup current of Ground High Current Lockout Element.
This value is the minimum operating current of Ground High Current
Lockout Element.
PRIMARY SETTING / PROTECTION / H/C LOCKOUT-PHA / Time Delay
Range
0.00 ~ 10.00 sec
Default
0.00
Step
0.01 sec
The Time delay of phase high current trip setting programs a definite
time delay for the phase high current trip. If set to zero, phase high
current trip operates instantaneously.
PRIMARY SETTING / PROTECTION / H/C LOCKOUT-PHA / Active Trip
Range
OFF, 1 ~ 5
Default
OFF
Step
1
If Active Trip = OFF, the feature is not operate.
If Active Trip = 2, then phase high current trip is enabled for the
second trip operation and every following trip operation.
[ H/C LOCKOUT-PHA ]
Pickup(A): 8000
Time Delay: 0.00
>Active Trip: OFF
[ H/C LOCKOUT-PHA ]
Relays(0-8): OFF
Pickup(A): 8000
>Time Delay: 0.00
[ H/C LOCKOUT-PHA ]
Function: OFF
Relays(0-8): OFF
>Pickup(A): 8000
