Table 7-7. Definite Time
Curves
α β γ
Rt
Definite Time 1sec 0.0 - 1.0 1.0
Definite Time 10sec 0.0 - 10.0 10.0
Table 7-8. Non Standard Curves
McGraw-Edison recloser curves
Phase Ground
Old New Old New
A 101 1 102
B 117 2 135
C 133 3 140
D 116 4 106
E 132 5 114
F 163 6 136
H 122 7 152
J 164 8 113
KP 162 8* 111
L 107 9 131
M 118 11 141
N 104 13 142
P 115 14 119
R 105 15 112
T 161 16 139
V 137 17 103
W 138 18 151
Y 120 KG 165
Z 134 - -
