RECLOSER CONTROL EVRC2A-N6,NT http://www.entecene.co.kr
219
ENHANCED TECHNOLOGY
The fault locator settings are as follows :
PRIMARY SETTING / MONITORING / FAULT LOCATOR \ Function
Range
OFF, ON
Default
OFF
Step
~
If function = OFF, the feature is not operational.
If function = ON, the feature is operational.
PRIMARY SETTING / MONITORING / FAULT LOCATOR \ Feeder Length
Range
0.1 ~ 99.9 km
Default
50.0
Step
0.1 km
Enter the total length of the feeder in kilometers
PRIMARY SETTING / MONITORING / FAULT LOCATOR \ Z1-Resistive
Range
0.1 ~ 6000.0
Default
10.0
Step
0.1
Enter the total real components of the feeder positive sequence
impedance, in actual ohms.
PRIMARY SETTING / MONITORING / FAULT LOCATOR \ Z1-Inductive
Range
0.1 ~ 6000.0
Default
10.0
Step
0.1
Enter the total imaginary components of the feeder positive sequence
impedance, in actual ohms.
PRIMARY SETTING / MONITORING / FAULT LOCATOR \ Z0-Resistive
Range
0.1 ~ 6000.0
Default
10.0
Step
0.1
Enter the total real components of the feeder zero sequence impedance,
in actual ohms.
PRIMARY SETTING / MONITORING / FAULT LOCATOR \ Z0-Inductive
Range
0.1 ~ 6000.0
Default
10.0
Step
0.1
Enter the total imaginary components of the feeder zero sequence
impedance, in actual ohms.
[FAULT LOCATOR]
Z1(IND) : 10.0
Z0(RES) : 10.0
>Z0(IND) : 10.0
[FAULT LOCATOR]
Z1(RES) : 10.0
Z1(IND) : 10.0
>Z0(RES) : 10.0
[FAULT LOCATOR]
Length(km) : 50
Z1(RES) : 10.0
>Z1(IND) : 10.0
[FAULT LOCATOR]
Function : OFF
Length(km) : 50.0
>Z1(RES) : 10.0
[FAULT LOCATOR]
Function : OFF
>Length(km) : 50.0
Z1(RES) : 10.0
[FAULT LOCATOR]
>Function : OFF
Length(km) : 50.0
Z1(RES) : 10.0
