10.1.8. System
The following values are contained in the system metering.
y Board power(±12, +5V)
y Temperature(℃)
y Battery voltage(V)
y Gas pressure(Bar)
NOTE :
According to recloser type, there may be no gas pressure measurement.
You can confirm in “MAIN NEMU / METERING / SYSTEM”
MAIN MENU / METERING / SYSTEM
System metering display.
10.1.9. Unbalance
The following values are contained in the unbalance metering.
y Voltage unbalance(V2/V1) – Source Side
y Voltage unbalance(V2/V1) – Load Side
y Current unbalance(I2/I1)
You can confirm in “MAIN NEMU / METERING / UNBALANCE”
MAIN MENU / METERING / SYSTEM
Unbalance metering display.
NOTE :
This menu is supported from version 6.12 of EVRC2A-N6,NT.
[UNBALANCE- %]
SOURCE-VOLT: 0
LOAD-VOLT: 0
CURRENT: 0
[ SYSTEM METER]
+12:12.35 –12:-12.38
+5 : 5.12 TMP:27.58
BAT:27.44 GAS: 0.00
