MAIN MENU / EVENT RECORDER / FAULT CYCLE
Ⓐ
Ⓑ
Ex>
Move to ”MAIN MENU / EVENT RECORDER / FAULT CYCLE” to
see Fault cycle summary
y To see previous value, press [▲] key.
y To see next value, press [▼] key.
On screen Ⓐ use [◀] or [▶] key to see Ⓐ, Ⓑ screen in term.
① Fault No: There are 32 events are recorded and the latest event is
displayed in advance.
② Fault Type
- Fault Pickup
- 27: Under Voltage Trip
- 59: Over Voltage Trip
- 81: Under Frequency Trip
- A, B, C, G: Fault phase shows LED ON.
- S: Sensitive Earth Fault
- Q: Negative Sequence Fault
- O: Other Trip(Demand Current Trip, Loss of Phase etc.)
③ Each phase fault current unit : Ampere(A)
④ Event occurred time
: Year/Month/Day(or Month/Day/Year) Hour: Minute: Second
⑤ Fault Location
Indicated when “Fault Locater” function is ON.
For more details about settings of “Fault Locater” function, refer to
“8.6. Fault Locator”.
[NO-①] Locate: --⑤
IS: ③
IQ: ③
④10/01/01 19:51:58
[NO-①] ②
IA: ③ IB: ③
IC: ③ IG: ③
④10/01/01 19:51:58
[NO-01] Fault Pickup
IA: 0 IB: 0
IC: 0 IG: 0
10/01/01 19:51:58
[NO-01] Locate: ---
IS: 0
IQ: 0
10/01/01 19:51:58
