3.1.2. Local Control Section
All indicators show status of Control function. The indicators are continuously ON when the
control function is enabled and the indicators are continuously OFF when control function is
DISABLE. The push-button toggles Enable/Disable.
PROTECTION ENABLED
All Protection elements are enabled
GROUND ENABLED
Ground Protection elements are enabled
SEF ENABLED
SEF Protection elements are disabled
RECLOSE ENABLED
Reclose function is enabled
CONTROL LOCKED
Front panel function is unlocked
REMOTE ENABLED
Remote control is enabled
ALTERNATE SETTINGS
Alternate setting is disabled
Primary Setting is enabled
PROGRAM 1
Program 1 function is disabled
PROGRAM 2
Program 2 function is disabled
HOT LINE TAG
Hot Line Tag function is disabled
Figure 3-3. Local Control Section
