PORT4(RJ-45) – Option
The Port4 is a Ethernet port for TCP/IP communication (10 BASE-T /100 BASE-T speed) for
Modbus, IEC60870-5-104 or DNP3.0 Protocol. A user can select the protocol and configure the
Port4 for the selected protocol by changing its settings.
NOTE:
From EVRC2A version 5.30, if a setting related with communication is changed and
then saved, the changed setting is applied after rebooting.
During IEC60870-5-104 or DNP3.0 communication through Port2, Port3 or Port 4, a user can
connect with the Interface Software “ETIMS(ENTEC Integration Management Software)” and
use it.
Please refer to “DNP3.0 Protocol Technical Manual”, “MODBUS Protocol Technical Manual”
or “IEC60870-5-101/-104 Protocol Technical Manual” for more information about setting for
each protocol.
