RECLOSER CONTROL EVRC2A-N6,NT http://www.entecene.co.kr
51
ENHANCED TECHNOLOGY
COMMUNICATION/ PROTOCOL SETUP/ IEC870-5-101/ ADSU Addr Size*
Range
1 ~ 2
Default
2
Step
1
Enter the size of cause of transmission.
COMMUNICATION/ PROTOCOL SETUP/ IEC870-5-101/ Link Confirm*
Range
NEVER, ALWAYS
Default
ALWAYS
Step
~
Enter the Link layer confirm mode.
COMMUNICATION/ PROTOCOL SETUP/ IEC870-5-101/ Link Addr Size*
Range
1 ~ 2
Default
1
Step
1
Enter the size of link address.
COMMUNICATION/ PROTOCOL SETUP/ IEC870-5-101/ Rx Frame Size*
Range
0 ~ 261
Default
261
Step
1
Enter the maximum size of received frame.
COMMUNICATION/ PROTOCOL SETUP/ IEC870-5-101/ Rx Frame TO*
Range
0(OFF), 1 ~ 255 sec
Default
15
Step
1 sec
Enter the maximum amount of time to wait for a complete frame after
receiving the frame sync.
COMMUNICATION/ PROTOCOL SETUP/ IEC870-5-101/ Tx Frame Size*
Range
0 ~ 261
Default
261
Step
1
Enter the maximum size of transmitted frame.
[IEC60870-5-101]
>Tx Frame Size: 261
>COT Size : 1
>IOA Size : 2
[IEC60870-5-101]
>Rx Frame Size: 261
>Rx Frame TO : 15
>Tx Frame Size: 261
[IEC60870-5-101]
>Link Addr Size: 1
>Rx Frame Size: 261
>Rx Frame TO : 15
[IEC60870-5-101]
>Link Addr Size: 1
>Rx Frame Size: 261
>Link Addr Size: 1
[IEC60870-5-101]
>ADSU Addr Size: 2
>Link Confirm:ALWAYS
>Link Addr Size: 1
[IEC60870-5-101]
>ADSU Addr Size: 2
>Link Confirm:ALWAYS
>ADSU Addr Size: 2
