Port Configuration
3-97
3
CLI – The following example configures LACP parameters for ports 1-6. Ports 1-4
are used as active members of the LAG; ports 5 and 6 are set to backup mode.
Displaying LACP Port Counters
You can display statistics for LACP protocol messages.
Counter Information
Console(config)#interface ethernet 1/1 4-151
Console(config-if)#lacp actor system-priority 3 4-167
Console(config-if)#lacp actor admin-key 120 4-167
Console(config-if)#lacp actor port-priority 128 4-167
Console(config-if)#exit
.
.
.
Console(config)#interface ethernet 1/6
Console(config-if)#lacp actor system-priority 3
Console(config-if)#lacp actor admin-key 120
Console(config-if)#lacp actor port-priority 512
Console(config-if)#end
Console#show lacp sysid 4-170
Channel Group System Priority System MAC Address
-------------------------------------------------------------------------
1 32768 00-30-F1-B0-E7-A0
2 32768 00-30-F1-B0-E7-A0
3 32768 00-30-F1-B0-E7-A0
4 32768 00-30-F1-B0-E7-A0
5 32768 00-30-F1-B0-E7-A0
6 32768 00-30-F1-B0-E7-A0
Console#show lacp 1 internal 4-170
Channel group : 1
-------------------------------------------------------------------------
Oper Key: 120
Admin Key: 120
Console#
Table 3-7. LACP Port Counters
Field Description
LACPDUs Sent Number of valid LACPDUs transmitted from this channel group.
LACPDUs Received Number of valid LACPDUs received on this channel group.
Marker Sent Number of valid Marker PDUs transmitted from this channel group.
Marker Received Number of valid Marker PDUs received by this channel group.
LACPDUs Unknown Pkts Number of frames received that either (1) Carry the Slow Protocols
Ethernet Type value, but contain an unknown PDU, or (2) are addressed
to the Slow Protocols group MAC Address, but do not carry the Slow
Protocols Ethernet Type.
LACPDUs Illegal Pkts Number of frames that carry the Slow Protocols Ethernet Type value, but
contain a badly formed PDU or an illegal value of Protocol Subtype.
