Priority Commands
4-221
4
Default Setting
The DSCP default values are defined in the following table. Note that all the
DSCP values that are not specified are mapped to CoS value 0.
Command Mode
Interface Configuration (Ethernet, Port Channel)
Command Usage
• The precedence for priority mapping is IP Port, IP Precedence or IP DSCP,
and default switchport priority.
• DSCP priority values are mapped to default Class of Service values
according to recommendations in the IEEE 802.1p standard, and then
subsequently mapped to the four hardware priority queues.
• This command sets the IP DSCP priority for all interfaces.
Example
The following example shows how to map IP DSCP value 1 to CoS value 0:
show map ip port
Use this command to show the IP port priority map.
Syntax
show map ip port [interface]
interface
- ethernet unit/port
- unit - This is device 1.
- port - Port number.
- port-channel channel-id (Range: 1-6)
Mapping IP DSCP to CoS Values
IP DSCP Value CoS Value
0 0
8 1
10, 12, 14, 16 2
18, 20, 22, 24 3
26, 28, 30, 32, 34, 36 4
38, 40, 42 5
48 6
46, 56 7
Console(config)#interface ethernet 1/5
Console(config-if)#map ip dscp 1 cos 0
Console(config-if)#
