Configuring the Switch
3-8
3
* Configurable on the V2H124-24P only.
Basic Configuration
Displaying System Information
You can easily identify the system by providing a descriptive name, location and
contact information.
Field Attributes
• Model Number – The switch model number.
• S/W Version # – The current software version number.
• System Name – Name assigned to the switch system.
• Object ID – MIB II object ID for switch’s network management subsystem.
• Location – Specifies the system location.
• Contact – Administrator responsible for the system.
• System Up Time – Length of time the management agent has been up.
These additional parameters are displayed for the CLI.
• MAC Address – The physical layer address for this switch.
• Web server – Shows if management access via HTTP is enabled.
• Web server port – Shows the TCP port number used by the web interface.
• Web secure server – Shows if management access via HTTPS is enabled.
• Web secure server port – Shows the TCP port used by the HTTPS interface.
• Telnet server – Shows if management access via Telnet is enabled.
• Telnet server port – Shows the TCP port number used by Telnet.
• POST result – Shows results of the power-on self-test.
Static Multicast Router Port
Configuration
Assigns ports that are attached to a neighboring multicast router/
switch
3-175
IP Multicast Registration
Table
Displays all multicast groups active on this switch, including
multicast IP addresses and VLAN ID
3-176
IGMP Member Port Table Indicates multicast addresses associated with the selected VLAN 3-177
DNS 3-178
General Configuration Enables DNS; configures domain name and domain list; and
specifies IP address of name servers for dynamic lookup
3-178
Static Host Table Configures static entries for domain name to address mapping 3-180
Cache Displays cache entries discovered by designated name servers 3-182
Table 3-2. Switch Main Menu (Continued)
Menu Description Page
