Enterasys Matrix-V V2H124-24 User Manual

Navigating the Web Browser Interface
3-7
3
Basic Information Displays basic information on the VLAN type supported by this
switch
3-147
Current Table Shows the current port members of each VLAN and whether or
not the port supports VLAN tagging
3-148
Static List Used to create or remove VLAN groups 3-149
Static Table Modifies the settings for an existing VLAN 3-150
Static Membership by Port Configures membership type for interfaces, including tagged,
untagged or forbidden
3-152
Port Configuration Specifies default PVID and VLAN attributes 3-153
Trunk Configuration Specifies default trunk VID and VLAN attributes 3-153
Priority 3-156
Default Port Priority Sets the default priority for each port 3-156
Default Trunk Priority Sets the default priority for each trunk 3-156
Traffic Classes Maps IEEE 802.1p priority tags to output queues 3-157
Traffic Classes Status Enables/disables traffic class priorities (not implemented) 3-156
Queue Mode Sets queue mode to strict priority or Weighted Round-Robin 3-159
Queue Scheduling Configures Weighted Round Robin queueing 3-159
IP Precedence/DSCP Priority
Status
Globally selects IP Precedence or DSCP Priority , or disables both 3-161
IP Precedence Priority Sets IP Type of Service priority, mapping the precedence tag to a
class-of-service value
3-162
IP DSCP Priority Sets IP Differentiated Services Code Point priority, mapping a
DSCP tag to a class-of-service value
3-163
IP Port Priority Status Globally enables or disables IP Port Priority 3-165
IP Port Priority Sets TCP/UDP port priority, defining the socket number and
associated class-of-service value
3-165
Copy Settings Enables mapping IP Precedence, DSCP Priority and IP Priority
settings to ports, or trunks.
3-166
ACL CoS Priority Sets the CoS value and corresponding output queue for packets
matching an ACL rule
3-168
ACL Marker Change traffic priorities for frames matching an ACL rule 3-169
IGMP Snooping 3-171
IGMP Configuration Enables multicast filtering; configures parameters for multicast
query
3-171
Multicast Router
Port Information
Displays the ports that are attached to a neighboring multicast
router/switch for each VLAN ID
3-174
Table 3-2. Switch Main Menu (Continued)
Menu Description Page
