Configuring the Switch
3-2
3
Navigating the Web Browser Interface
To access the Web-browser interface you must first enter a user name and
password. The administrator has Read/Write access to all configuration parameters
and statistics. The default user name and password for the administrator is “admin.”
Home Page
When your Web browser connects with the switch’s Web agent, the home page is
displayed as shown below. The home page displays the Main Menu on the left side
of the screen and System Information on the right side. The Main Menu links are
used to navigate to other menus, and display configuration parameters and
statistics.
Figure 3-1. Home Page
Configuration Options
Configurable parameters have a dialog box or a drop-down list. Once a configuration
change has been made on a page, be sure to click on the Apply button to confirm
the new setting. The following table summarizes the Web page configuration
buttons.
Table 3-1. Configuration Options
Button Action
Apply Sets specified values to the system.
Revert Cancels specified values and restores current values prior to pressing Apply.
Help Links directly to webhelp.
