VLAN Commands
4-201
4
Default Setting
None
Command Mode
Global Configuration
Example
The following example shows how to set the interface configuration mode to
VLAN
1, and then assign an IP address to the VLAN:
Related Commands
shutdown (4-156)
switchport mode
Use this command to configure the VLAN membership mode for a port. Use the no
form to restore the default.
Syntax
switchport mode {trunk | hybrid}
no switchport mode
• trunk - Specifies a port as an end-point for a VLAN trunk. A trunk is a direct
link between two switches, so the port transmits tagged frames that identify
the source VLAN. Note that frames belonging to the port’s default VLAN (i.e.,
associated with the PVID) are transmitted as tagged frames.
• hybrid - Specifies a hybrid VLAN interface. The port may transmit tagged or
untagged frames.
Default Setting
All ports are in hybrid mode with the PVID set to VLAN 1.
Command Mode
Interface Configuration (Ethernet, Port Channel)
Example
The following shows how to set the configuration mode to port 1, and then set the
switchport mode to hybrid:
Console(config)#interface vlan 1
Console(config-if)#ip address 192.168.1.254 255.255.255.0
Console(config-if)#
Console(config)#interface ethernet 1/1
Console(config-if)#switchport mode hybrid
Console(config-if)#
