Basic Configuration
3-15
3
Manual Configuration
Web – Click System, IP. Select the VLAN through which the management station is
attached, set the IP Address Mode to “Static,” enter the IP address, subnet mask and
gateway, then click Apply
.
Figure 3-6. VLAN IP Configuration
CLI – Specify the management interface, IP address and default gateway.
Console#config
Console(config)#interface vlan 1 4-151
Console(config-if)#ip address 192.168.1.24 255.255.255.0 4-234
Console(config-if)#exit
Console(config)#ip default-gateway 10.2.13.254 4-235
Console(config)#
