Configuring the Switch
3-134
3
Web – Click Spanning Tree, STA Port Information or STA Trunk Information.
Figure 3-82. Displaying STA - Port Status Information
CLI – This example shows general STA configuration and attributes for all ports.
Console#show spanning-tree ethernet 1/5 4-196
Eth 1/ 5 information
--------------------------------------------------------------
Admin status : enable
Role : disable
State : discarding
External path cost : 10000
Internal path cost : 10000
Priority : 128
Designated cost : 200000
Designated port : 128.5
Designated root : 61440.0.0000E9313131
Designated bridge : 61440.0.0000E9313131
Fast forwarding : enable
Forward transitions : 0
Admin edge port : enable
Oper edge port : enable
Admin Link type : auto
Oper Link type : point-to-point
Spanning Tree Status : enable
Console#
