C8-B/C12-B Service Manual Maintenance Disclosure Scope: Maintenance Trained Personnel Only
(C) Seiko Epson Corporation 2-89 Rev.1
2.5 Joint #3
2.5.1 Joint #3 Replacing the Timing Belt
J3 Timing Belt
Arm2 Side Cover
S06: 4-M4x10
