C8-B/C12-B Service Manual Maintenance Disclosure Scope: Maintenance Trained Personnel Only
(C) Seiko Epson Corporation 2-311 Rev.1
2.14 Cover
Here, this explains the names of the covers using the typical "M/C Cable Backward Model (Standard Model/Cleanroom Model)".
S06: 4-M4x10
Arm2
Side Cover
Arm2 Side Cover
S06: 4-M4x10
Arm3 Cover
S06: 4-M4x10
Arm3 Maintenance Cover
S06: 4-M4x8
Arm4 Side Cover (right)
S06: 7-M4x10
S06: 7-M4x10
S06: 4-M4x10
Arm4 D-sub
Attachment
S01: 2-M4x10
Arm4 Side Cover (left)
Arm4 Maintenance Cover
