2.1.2 Viewing the Maintenance Page
Each page is configured as shown below.
Top page of each section
The exploded view shows all parts and units that need to be removed and reinstalled in the
section.
About the bolt and screw type
S01 indicates the bolt or screw type.
For details on the type, the size, torque value, etc., refer to 1.2.6 Tightening Bolts/Screws.
S01: 3-M4x20
Notation of product names in the manual
In this manual, the model name is used to
describe where the bolt/screw type or work
procedure differs depending on the model
number or model name.
Model Number
Model Name
C8-B901***
C8L
C8-B1401***
C8XL
C12-B1401**
C12XL
