Epson C8-B - C12-B

C8-B/C12-B Service Manual Exploded View/Maintenance Parts List Disclosure Scope: Maintenance Trained Personnel Only
(C) Seiko Epson Corporation 5-13 Rev.1
5.2.2 C12-B
Ref. No.
Parts Name
Parts Code
Note
Overhaul
001
Timing Belt
1655930
Joint #1

002
Motor
2232752
Joint #1

003
Brake
2172926
Joint #1, Joint #2

004
Reduction Gear Unit
1674604
Joint #1

005
Timing Belt
1655927
Joint #2

006
Motor
2230547
Joint #2

007
Reduction Gear Unit
1674606
Joint #2

008
Timing Belt
1655919
Joint #3

009
Motor
2230549
Joint #3

010
Brake
2172927
Joint #3

011
Reduction Gear Unit
1654199
Joint #3

012
Timing Belt
1655931
Joint #4

013
Motor
2230550
Joint #4, Joint #5, Joint #6

014
Brake
2172928
Joint #4, Joint #5, Joint #6

015
Reduction Gear Unit
1821978
Joint #4

016
Timing Belt
1655932
Joint #5

017
Timing Belt
1655933
Joint #6

020
Gyro Board 1
2228302
021
Gyro Board 2
2228303
022
DC/DC Board
2224571
