2.14.12 Arm4 D-sub Attachment
Standard Model/Cleanroom Model
Remove the Arm4 D-sub attachment.
CAUTION
• Cables are connected internally, so do not pull with force when removing.
• When installing the attachment, be careful not to pinch the cables. Also, do not bend or
push the cables in using excessive force.
1
S01: 2-M4x10
A
Arm4 D-sub attachment
1
