5.2 Maintenance Parts List
5.2.1 C8-B
Ref. No.
Parts Name
Parts Code
Note
Overhaul
001
Timing Belt
1655929
Joint #1 (C8L-B)

002
Timing Belt
1655930
Joint #1 (C8XL-B)

003
Motor
2232752
Joint #1

004
Brake
2172926
Joint #1, Joint #2

005
Reduction Gear Unit
1674603
Joint #1 (C8L-B)

006
Reduction Gear Unit
1674604
Joint #1 (C8XL-B)

007
Timing Belt
1655924
Joint #2 (C8L-B)

008
Timing Belt
1655927
Joint #2 (C8XL-B)

009
Motor
2230547
Joint #2

010
Reduction Gear Unit
1674605
Joint #2 (C8L-B)

011
Reduction Gear Unit
1674606
Joint #2 (C8XL-B)

012
Timing Belt
1655918
Joint #3 (C8L-B)

013
Timing Belt
1655919
Joint #3 (C8XL-B)

014
Motor
2230549
Joint #3

015
Brake
2172927
Joint #3

016
Reduction Gear Unit
1933056
Joint #3 (C8L-B)

017
Reduction Gear Unit
1674608
Joint #3 (C8XL-B)

018
Timing Belt
1655931
Joint #4

019
Motor
2232753
Joint #4, Joint #5, Joint #6

020
Brake
2172928
Joint #4, Joint #5, Joint #6

021
Reduction Gear Unit
1674609
Joint #4 (C8L-B)

022
Reduction Gear Unit
1675434
Joint #4 (C8XL-B)

